Titanium anodes are critical components in PCB (Printed Circuit Board) horizontal copper plating—an advanced process that deposits uniform, high-purity copper layers on PCB substrates (e.g., double-sided or multi-layered boards). Their unique properties address the strict requirements of horizontal plating, such as consistent current distribution, corrosion resistance, and compatibility with acidic plating baths.
In horizontal copper plating, PCBs move continuously through a horizontal plating tank, where a thin, even copper layer is electrochemically deposited on exposed copper pads, traces, or vias.
Titanium anodes act as insoluble anodes in this process (replacing traditional soluble copper anodes in some setups) or as auxiliary anodes to regulate current. Their primary role is to:Provide stable, uniform current distribution across the moving PCB surface, ensuring consistent copper thickness (critical for high-density PCBs with fine-pitch components).Resist corrosion in the acidic plating bath (typically sulfuric acid + copper sulfate, pH 0.5–2.0) and avoid contaminating the bath with anode debris.
Key Advantages Over Traditional Anodes
Compared to soluble copper anodes or other insoluble options (e.g., lead-based anodes), titanium anodes offer distinct benefits for PCB horizontal plating:
Application Scenarios
Titanium anodes are widely used in high-precision, high-volume PCB manufacturing, including:
High-Density Interconnect (HDI) PCBs: For smartphones, laptops, and wearables, where uniform copper plating on micro-vias (diameter <0.1 mm) is critical.
Automotive PCBs: For ADAS (Advanced Driver-Assistance Systems) or EV (Electric Vehicle) controllers, which require thick, durable copper layers (20–50 μm) for heat dissipation.
Multi-Layer PCBs: For industrial equipment or aerospace electronics, where horizontal plating ensures consistent copper thickness across multiple layers and blind vias.
Who we are?
Qixin titanium Co.Ltd, is a leading manufacturer specializing in coated titanium anode. With an extensive historyand a wealth of expertise, we have been dedicated to providing high-quality products and solutions to variousindustries for many years.Our company was established 2006, and since then, we have accumulated 18 years of valuable manufacturingexperience. This experience has enabled us to master the art and science of producing top-notch coated titaniumanodes that meet the most stringent quality standards.We take pride in our state-of-the -art manufacturing facilities and a team of highly skilled professionals. Ourengineers and technicians are experts in the field, constantly researching and innovating to improve our productsand processes.
Production
Brush coating.
Specific operation as follows:
Firstly,making the coating solution according to the type and the area of the platinum electrode; secondly ,put the solution on the surface evenly, then put them into the drying furance for drying; thirdly,we need to oxidate in the high temperature oxidation furance;Lastly, dry it to room temperature. Then,repeat these steps until you run out the configuration solution.
Certification
Qixin is ISO 9001:2015 certified and own more than 10 patents. All its processes and procedures are documented and controlled in accordance with these standard. Qixin has strict product quality control procedure, from raw material to finished product, all the process is tested qualified to assure high quality product.
With technical engineers experienced for more than 18 years of constant research and production for titanium electrode and its application in various industries, Qixin can offer a very high level of technical support and products, which are among its most remarkable characteristics.
